JetCentral JETI Telemetry Adapter V2

Small and lightweight telemetry adapter; you will get all the information from directly the turbine to your transmitter.

Supported System: Jeti
Size: 17mm x 37mm
Weight: 6g
Consumption: 32mA

Jet Central telemetry display for Jeti DC/DS-24, DS-12 Transmitters

FOR DISPLAY TELEMETRY WITH LUA APP YOU REQUIRE:

Requisites:

Updated V2 Jeti Telemetry Module from Jet Central
Transmitter firmware version 4.27 LUA or above

Installation:

For single-engine:

Download JCHDT.lc to Apps folder in your transmitter, File for the DS/DC-24/16G2/14G2 or DS-12 can be downloaded HERE for DC/DS-16G1 require the file HERE
Download/JetCentral/CF.png (for the color version) or
Download/JetCentral/BLK.png (for the Black version).
to the Apps/JetCentral/ folder in your transmitter IMPORTANT: RENAME DE FILE TO CF.png or BLK.png (If the folder doesn't exist, create a folder called JetCentral inside the Apps folder) Image File for the DS/DC-24, DS-16 or DS-12 can be download

Color Version HERE

Black Version HERE

Go to: Menu > Applications > User Applications
Press [F3][+] and select JCHDT.lc
You can configure the App in Menu > Timers/Sensors > JetCentral HDT
Add "JetCentral HDT" in Menu > Timers/Sensors > Displayed Telemetry for full telemetry display or...
Add "JetCentral MFD" for a small telemetry display

For multi-engine:

Download JCTwin.lc to the Apps folder in your transmitter, Files for the DS/DC-24/16G2/14G2 or DS-12 can be downloaded HERE
Download /JetCentral/CFTwin.png to the Apps/JetCentral/ folder in your transmitter IMPORTANT: RENAME DE FILE TO CFTwin.png (If the folder doesn't exist, create a folder called JetCentral inside the Apps folder) Image File for the DS/DC-24 or DS-12 can be downloaded HERE
Go to: Menu > Applications > User Applications
Press [F3][+] and select JCHDT.lc
You can configure the App in Menu > Timers/Sensors > JetCentral HDT
Add "JetCentral HDT" in Menu > Timers/Sensors > Displayed Telemetry for full telemetry display or...
Add "JetCentral MFD" for a small telemetry display
